F2164 GPRS GSM modem for AMR/SCADA/PLC/RTU GPRS Q26 gsm gprs rtu humidity and temperature data logger
F2x64 series is wireless remote terminal unit(abbreviation:RTU). RTU has many functions (analog input,switch input,switch output,pulse counting and wireless data communication ect).
It adopts high-powered industrial 32 bits CPU and embedded real time operating system. It supports RS232 and RS485 (or RS422) port that can conveniently and transparently connect one device to a cellular network, allowing you to connect to your existing serial devices with only basic configuration. It has low power consumption states in which the power consumption could be 1ower than [email protected] It has compatible digital I/O channel, ADC, input pulse counter and pulse wave output function.
Design for Indstrial Application
High-powered indstrial celllar modle
High-powered indstrial 32 bits CP
support low power consmption mode, inclding mlti-sleep and trigger modes to redce the power dissipation farthest
Embedded Real Time Clock(RTC) circit which can realize timing online/offline fnction
Hosing: iron, providing IP30 protection.
Power range: DC 5~35V
Stability and Reliability
support hardware and software WDT
support ato recovery mechanism, inclding online detect, ato redial when offline to make it always online
RS232/RS485/RS422 port: 15KV ESD protection
SIM/IM port: 15KV ESD protection
Power port: reverse-voltage and overvoltage protection
Antenna port: lightning protection(optional)
Standard and Convenient
Adopt terminal block interface, convenient for indstrial application
support standard RS232 and RS485(or RS422) port that can connect to serial devices directly
TTL logic level RS232 interface can be cstomized
support intellectal mode, enter into commnication state atomatically when powered
Provide management software for remote management
support several work modes
Convenient configration and maintenance interface
8 ch acqisition analog inpt(resoltion:16bit)Inpt voltage(0-5V),Inpt crrent(0-20mA), Sampling rate(1.365kSPS) ,Accracy ±0.5% or better
4 ch relay otpt(5A/30VDC,5A/250VAC)
4 ch optocopler isolation otpt,open collector to 30V,40mA max.load,power consmption 125mW
8 ch Digital inpt(“0”:0-3.3V,“1”:5-24V). Contains all the way cont fnction
2MB SPI FLASH
support dal data centers, one main and another as backp
support mltiple data centers , it can support maximm 5 data centers
support mlti-center mlti-fnction(for example: one data center is MODBS RT protocol fnction, another data center is RT extended protocol fnction)
support mltiple online trigger ways, inclding SMS, ring and data. support link disconnection when timeot
support dynamic domain name(DDNS) and IP access to the data center
support RS232/RS485 MODBS RT protocol
support TCP MODBS RT protocol sing TCP2COM software that converts TCP to virtal serial port
support 8 digital inpts and 8 analog inpt manal qery and atomatic report
support 4 optocopler isolated otpt ports and 4 relay otpts controlled via MODBS RT protocol
support plse conter initiate vale configrable, Its realtime vale can be qeried via MODBS RT protocol
support RT extended protocol.
Acqisition data(8 analog inpts and 8 digital inpts) is reported periodically via RT extended RT protocal.
support RT extended protocol. Reporting mode can be selected. there are three reporting mode, inclding Network only, SMS only and Main network SMS backp(it ses SMS. when network connect fail)
support RT extended protocol.When reporting acqisition data failre, acqisition data are saved to 2M byte SPI FALSH
support RT extended protocol. The data center can qery acqisition data actively
support RT extended protocol. It has conter fnction that the initial vale of the timer is set and the vale of the timer is qeried
support RT extended protocol. It has the data center and RS232/RS485 transparent transmission fnction
support RT extended protocol. it has alarm fnction, alarm information is reported atomatically(alarm trigger conditions can be configred independently).
support RT extended protocol. Can remotely reboot RT
support RT extended protocol. Can remotely configre the parameters
support RT extended protocol. The remote pgrading parameters can be configred, RT support remote pgrade firmware.
Alarm fnction: Alarm information are reported throgh RT extended protocol , SMS, or both SMS and RT extended protocol
When alarm information are reported throgh SMS, alarm nmber and alarm content of each channel can be configred independently
The remote pgrading parameters can be configred by SMS. RT pgrade the firmware immediately when it received the pgrade command.
Bilt-in indstrial clock, the acqisition time can be recorded throgh this clock
Network is atomatically connected, when device power on. Network is atomatically reconnected when network is offline.
Schedled trn on and trn off power fnction make the device work in low-power mode
Data transmission | Remote Terminal Unit |
Industrial cellular module
Standard and Band
Compliant to GSM phase 2/2+
GPRS class 10, class 12(optional)
Industrial 32 bits CPU
1 RS232 port and 1 RS485 port, 15KV ESD protection
Data bits: 5, 6 ,7, 8
Stop bits: 1, 1.5, 2
Parity: none, even, odd, space, mark
Baud rate: 110~230400 bps
"Power", "ACT", "Online"
Standard SMA female interface, 50 ohm, lighting protection(optional)
Standard 3V/1.8V user card interface, 15KV ESD protection
Terminal block interface, reverse-voltage and overcurrent protection
Timing Power Off
Iron, providing IP30 protection
