Официальный акционный маленький мотогрейдер 215hp GR2153 с задним рычагом на продажу

Официальный акционный маленький мотогрейдер 215hp GR2153 с задним рычагом на продажу

Category: Motor Graders >>>
Seller: Cruking,Engineering,Equipment,(Xiamen),Co.,Ltd.

Price in USD:

Price:25 000,00 $ - 30 000,00 $

Quantity:

add to wishlist

Product Overview

Description

official promotional small 215hp Motor Grader GR2153 with rear ripper for Sale

Contact Info

Scarlet Li

Cruking Engineering Equipment (Xiamen) Co., Ltd.
Cruking Asia Limited
Whatsapp/Wechat/Mobile: +86-13486811784
E-mail: [email protected]

Products Description

Advantages and Highlights:

1.Energy-saving and noise-reducing: adopt low-speed engine transmission line, low specific fuel consumption of rated point, energy saving and environmental protection; low-speed ratio configuration of transmission system, average fuel consumption reduced by about 8%

2.Strong Power: Adopting High-efficiency State III Variable Power Engine

3.With load rotation: to improve the hydraulic system pressure, blade rotary force greatly improved, high-frequency quenching gear ring, wear resistance and life expectancy, to achieve load rotation.

4.Efficient operation: The displacement of the hydraulic pump and the hydraulic motor is increased, the speed of the cylinder is increased by 20%, and the operating efficiency leads the industry.

Product Paramenters

Item					GR2153
Basic parameters	Engine model			QSB6.7
		Rated power/speed			164kW/2000rpm
		Overall dimension (standard)			8970x2625x3420
		Total weight (standard)			16500 kg
		Tire specification			17.5-25
		Ground clearance (front axle)			430mm
		Tread			2156mm
		Space of front and rear axles			6219 mm
		Space of middle and rear wheels			1538 mm
Performance parameters	Forward velocity			5,8,11,19,23,38km/h
		Reverse speed			5,11,23km/h
		Tractive effort f=0.75			85 kN
		Maximum gradeability			≥25%
		Tire inflation pressure			260kPa
		Working system pressure			20MPa
		Transmission pressure			1.3—1.8Mpa
Working parameters	Maximum steering angle of front wheel			±48°
		Maximum slant angle of front wheel			±17°
		Maximum oscillating angle of front axle			±15°
		Maximum oscillating angle of equilibrium box			±15°
		Maximum steering angle of frame			±27°
		Minimum turning radius			7.3m
		Scrape knife	Maximum lift height	400mm
				Maximum cutting depth	500mm
				Maximum tilt angle	90°
				Cutting angle	28°—70°
				Angle of revolution	360°
				Length & chord height	4270x610mm
Oil filling amount	Coolant			50L
		Fuel tank			280L
		Engine			24L
		Transmission			38L
		Balancing box			46L
		Drive axle			28L
		Hydraulic oil			110L
