Датчик давления воды Zigbee

Zigbee Water Pressure Sensor

Description

DBHZ93420 series intelligent liquid level pressure transmitter adopts HT series piezoresistive isolated membrance silicon oil filled sensing element as signal measuring element, according to the mathe matical model of the three relations of the measured liquid pressure, density, liquid level, through the liquid level sensor to accomplish the liquid level pressure measurement which is proportional to the depth of the liquid level. Through the built-in high performance microprocessor to do full range of digital correction to sensor nonlinearity, temperature drift and so on.

Features

Measurement range: 0~200m

Integrated structure

Protection level: IP68

Multiple output signals

Aluminium casting connection box

Intrinsic safety explosion-proof type

Conform to the state explosion protection standards

Explosion-proof certificated, explosion-proof sign: ExiaIICT6

Fully sealed stainless steel structure of the into liquid sensor part

Sensor and amplifier circuit is in complete sealed stainless steel case

Multiple protections, good leakage-proof performance, strong ability to resist electromagnetic interference

Applications

Liquid, gas which is compatible with 316L stainless steel

Applicable to liquid level measurement and control in the field of petroleum, chemical, power plants, urban water supply, hydrologic exploration
